1. Parts Designations and Functions
1-2 Parts Functions
The following table lists the functions of each part.
No. Part Name Functions
Light Receptor
Point light receptor directly at light source during reading. Head
rotates 270 degrees to aid reading.
Light Selection
Ring
Rotate to select dark calibration, normal measuring range or high
Power Button Press to turn ON/OFF.
Display Panel
Displays the setting screens and measuring screens. The built-
in touch panel function enables setting, selection or operation by
touching the display panel. (
P16)
Measuring Button Press for measurement.
Menu Button Press to shift display to Display Mode Selection screen.
Memory Button Press after measuring to save the measured data.
Battery Cover
Latch
Latch for the battery cover.
Battery Cover Secures the batteries.
Tripod Socket
Female mounting threads (1/4-20) for hands free mounting on
tripods.
USB Mini-B
Connector
The USB connector for connecting to the PC with the installed
utility and USB bus power.
USB terminal: Mini-B-5pin
Sync Terminal
Accepts an optional synchro cord when using meter in Cord (PC)
Flash Mode.
Strap Eyelet Used to attach the included strap.
Battery
Compartment
Holds the batteries. Insert the batteries in the correct direction.
