Sekonic C-800 User Manual

89
5. Measuring Light Sources [Measurement Screen]
5-3 Measurement in Cordless Flash Mode
use a sync cord or when wireless measuring is desired.
Operation
1.
On the Measuring screen, touch the [Measuring Mode] icon and
select the [Cordless Flash Mode] icon on the Measuring Mode
Selection screen.
Select the measuring mode. ( P22)
2.
Touch the [Target] indication.
Target CCT Input screen will be displayed. ( P26)
Set the color temperature.
Measuring Screen
Measuring Mode
Selection Screen
Measuring Screen
Measuring Screen Target CCT Input Screen

Sekonic C-800 Specifications

General

Dimensions (WxDxH)	73 x 183 x 27 mm
Interface	USB 2.0
USB powered	Yes

Weight and Dimensions

Weight	230 g
