Sekonic C-800 User Manual

20
4. Basic Operations
4.
Basic Operations
4-1 Basic Measurement Flow
The basic operations and screens are as follows. Measurements and measurement
changes are operated from the Measuring screen.
Make sure the Light Selection
Ring
is set to the dark
calibration position.
The user sets the measurement
functions depending on the
intention.
• Preset Selection
• Memory Title Setting
• Memory Management
[Recall and Edit (Rename/
Clear)]
The user sets the functions
depending on the intention.
• Customize (custom setting of
the meter)
• Edit a preset
• Dark calibration
• Display the information
Power ON
[Setting] Icon
[Close] Button
[Tool Box] Icon
Startup Screen
Dark Calibration
Measuring Screen
Setting Screen
Tool Box Screen
Measuring Screen
To the next page
Measuring Screen
