Sekonic C-800 User Manual

45
4. Basic Operations
4-4-5
Compares the current measurement value and memoried value to show the color
temperature and average CRI (Ra). Also individual CRI (R1 to R15) is displayed in
each graph.
Operation
1.
screen.
P30
2.
P22
3.
Press the Measuring Button to measure.
The Light Selection Ring should be set to L ( )
when taking ambient light measurements.
( )
or Range H
( ) depending on the brightness of
P100 P102)
Light Selection Ring
Measuring Button
Current
Measurement
Current Measurement
Graph (Individual CRI
Number)
[Memory Selection] Icon
[Measuring Mode] Icon
[Display Mode] Icon
CRI Comp. Mode
CRI Comp. Screen
Selected Memorized Value
Graph (Individual CRI
Number)
Selected Memorized
Value Display Area
CRI Number

Sekonic C-800 Specifications

General

Dimensions (WxDxH)	73 x 183 x 27 mm
Interface	USB 2.0
USB powered	Yes

Weight and Dimensions

Weight	230 g
