IN0016 Revision 12 Part # 004573 – 2 of 22
SP PRO Three Phase
Installation Notes
POWER PERFORMANCE PASSION
Introduction
SP PRO – Three Phase Installation Notes detail the installation and additional configuration for
three SP PRO series II inverters in a three phase inverter system. One SP PRO is installed per
phase and they are interlinked and configured to allow them to operate together. The L1 phase
is the prime controller of the three phase system. It controls the operation mode of the
system, the synchronisation to the AC source, controlling of the generator etc. The L2 and L3
phase SP PROs are controlled by the L1 phase SP PRO via each unit’s SYNC interface.
Note: This document needs to be read in conjunction with the SP PRO Instruction Manual and
SP LINK instruction manual (both found in SP LINK Help menu)
Note 2: Parameter locations will be shown as per the picture below or as a drill down structure,
such as Configuration Settings >Inputs / Outputs > Battery Charger Inputs > Initial Stage Input
