Selectronic SP PRO - Installation Checklist

IN0016 Revision 12 Part # 004573 – 3 of 22
POWER PERFORMANCE PASSION
SP PRO Three Phase
Installation Notes
Installation checklist
The following table summarises the steps taken to set up a three phase SP PRO system. Once
the system has been installed, use the following checklist to ensure that each step has been
completed.
Refer to the pages following the tables for detailed information on each of the installation steps.
Installation step
L1
L2
L3
Install SP PROs as per manual
Connect AC wiring
Connect Main DC wiring
Wire 800A shunt in L1, L2 and L3 Batt -ve
Wire 800A shunt sense wires to L1, L2
and L3 shunt 1. Note polarity
Pre-charge and Midpoint Wiring
Sync Interface connections
Charge stage linking
Battery temperature sensor installed
Turn on Pre-charge and check front panel
LEDs
Turn on main DC isolators. LEAVE
inverters in IDLE.
Configure Parameters in each SP PRO
(see SP PRO Configuration table below)
Verifying Phase Settings
1 flash / 2 sec
2 flash / 2 sec
3 flash / 2 sec
Test linking of charge stages
Test shunt 1, positive (+) means charging
negative (-) means discharging.
Zero all current shunts
Test system function
