IN0016 Revision 12 Part # 004573 – 4 of 22
SP PRO Three Phase
Installation Notes
POWER PERFORMANCE PASSION
SP PRO Configuration - Additional Configuration Settings
Parameter to be programed
L1
L2
L3
Multi Phase setting
(Configuration Settings > System)
L1-Primary
L2-Secondary
L3-Secondary
System – Multiple SP PRO Charging
(Configuration Settings > System)
Enable
Generator Fault input (When used)
(Configuration Settings > Input / Outputs >
Generator Inputs)
Digital control
input 3
none
External regulator control output
(Configuration Settings > Input / Outputs >
Extern. Regulator Outputs)
none
Check that Digital control input 1, Digital
control input 2, Digital control output 1 and
Digital control output 2 are not allocated.
(Configuration Settings > Expansion Card
Wiring Diagram)
none
Initial stage input
(Configuration Settings > Input / Outputs >
Battery Charger Inputs)
Digital control input 2
Initial stage edge
(Configuration Settings > Input / Outputs >
Battery Charger Inputs)
Rising
Float stage
(Configuration Settings > Input / Outputs >
Battery Charger Inputs)
Digital control input 1
Float stage edge
(Configuration Settings > Input / Outputs >
Battery Charger Inputs)
Rising
Initial stage output
(Configuration Settings > Input / Outputs >
Battery Charger Inputs)
Digital control output 2
Float stage output
(Configuration Settings > Input / Outputs >
Battery Charger Inputs)
Digital control output 1
Shunt 1
(Configuration Settings > Shunts)
System SoC
For a DC couple solar system – Set Shunt 2
name
(Configuration Settings > Shunts)
Solar
