3. Bedienungsanleitung
3-1. Anschlussdiagramm
Verwenden Sie das schwarze 5C Stromkabel um das Steuergerät mit der Antenne
zu verbinden.
Das 5C Stromkabel sieht dem Empfängerkabel sehr ähnlich, aber Sie können sie
anhand der Farbe und der Beschriftung unterscheiden.
Empfängerkabel
(grau)
5C Stromkabel
Stromversorgungskabel
Steuergerät
Haupteinheit
Empfänger
Fernseher
BATTERIE
zur Zündung
+
Ignition
-
