3. Operating Instruction
3-1. Connection Diagram
Use the 5C Power cable to connect between the controller and antenna.
The controller cable looks similar to the antenna receiver cable but you can distinguish
them by the color and labeling.
Receiver cable
(Grey color)
5C Power Cable
Power Input Cable
CONTROLLER
MAIN UNIT
RECEIVER
TV
BATTERY
to Ignition
+
Ignition
-
