SELTEX V350 - Dip Switch Settings; Configuring Gate Functions; Current Limit Adjustment

18
Second highest current limit.
Minimum current limit.
Maximum current limit (means also the worst sensibility, which
could shorten the life of motor, please try lower current limit first)
Approx. current limit values for different dip switch setting:
Current limit
Auto-Close Auto-Close timer Gate Type
ON
1 2 3 4 5 6
DIP
ON
1 2 3 4 5 6
DIP
ON
1 2 3 4 5 6
DIP
ON
1 2 3 4 5 6
DIP
The default setting of dip switches:
Setting of the Dip Switches:
2.7A
Switch 5
4.0A
Switch 6
1.4A
Switch 4
1 Auto-Close Yes No
2 Auto-Close timer 60 Sec 30 Sec
3 Gate Type Heavy Gate
4 ~ 6 Current Limit Selected Unselected
Light Gate
Key No. Function ON OFF
*Do not change the setting of Gate Type unless you have problem finishing the auto-learning process.
