Control box:
2. Unfasten the two screws and remove the
cover.
3. Fix the control box on the wall.
M8 screws are suggested (not provided).
AC12V
Auto ClearRF2
J1
O / C
LED1
BAT
- +
1 2 3 4 5 6
ON
Lamp
RF1
DIP
LED O/C1 O/C2 GND ANT
-
M2
+
-
M1
+ -
Warm
+
+12V
COM
GND
NC
Min. 60cm
AC12V
Auto ClearRF2
J1
O / C
LED1
BAT
- +
1 2 3 4 5 6
ON
Lamp
RF1
DIP
LED O/C1 O/C2 GND ANT
-
M2
+
-
M1
+ -
Warm
+
+12V
COM
GND
NC
1. Use a screw driver to unfasten the screws
of the cover and open the control box.
