SELTEX V350 - Motor Wire Battery Testing; Actuator Motor Wire Testing

7
bottom view
5mm
Normally the nut is at a distance of 5mm from the fully close position. You can drive the nut to this position,
in case the nut is not at the proper position.
- Move the nut with a battery. The below diagrams indicate which direction the nut moves when the motor
wires are connected directly to a 12VDC battery.
Black
Red
Red
Black
