Explanation of displays and buttons
3. Explanation of displays and buttons
Front view
View from behind
Status LED
UP button
DOWN button
STOP button
Manual/automatic
sliding switch
1 Upper position  alarm signal function ON
Lower position  alarm signal function OFF
(factory state)
2 Upper position  group controller
Lower position  motor controller (factory state)
3 Upper position  Local operation and extensions in
venetian blind mode
Lower position  Local operation and extensions in
roller shutter mode (factory state)
1 2 3
Encoding
switch
1 2 3
