Selve i-R Timer Plus - 4 Group Separation

GB
80
4.) Group separation
A group is an arrangement of several receivers which can be
controlled using one send channel.
If this group is divided
with the aim of assigning
a specific send channel
to each receiver, group
separation has to be
initiated.
During group separation,
each drive moves once
only, for 3 seconds, in
the space of approx.
2 minutes in a time slot
determined according to a random principle. If the drive is
stopped by any transmitter, this is learnt into the receiver.
If you would like to separate the receivers from a group which
have been learnt into a transmitter, proceed as follows:
Disconnect from the power supply
The receivers acknowledge the disconnection by means of a
brief movement of the drive.
Transmitter programming procedure
3 sec.
disconnect
from the
supply for
3 seconds
connect
to the
supply for
3 seconds
disconnect
from the
supply for
3 seconds
connect
to the supply
