Changing the battery
Note: Change the batteries within
one minute.
1. Take out the batteries.
2. Insert the new batteries in the
correct position.
Maintenance
Clean the device with a damp cloth only. Do not use a cleansing agent
since this could damage the plastic.
Technical data
Nominal voltage: 3 V DC
Battery type: LR 03 (AAA)
System of protection: IP 20
Permissible
ambient temperature: 0 to +55 °C
Installation: Wall mounted
Radio frequency: 868,3 MHz
The maximum radio range is up to 25 m indoors and up to 350 m in
the open.
Subject to technical modifications.
General conformity declaration
The company SELVE GmbH & CO. KG, hereby declares that the
i-R Timer Plus is in conformity with the basic requirements and other
relevant provisions of the Directive 1999/5/EC.
GB
Changing the battery/Technical Data
