4.3. Mechanic requirements
Operating of the SEL Plus drives is possible with normal safety and fixing springs.
Optionally, security springs can also be used (manual setup-mode).
For operating the SES security springs must be used.
If the drive is supposed to move against the stop in the upper end position, a stable
end stop must be installed!
If the drive is set in automatic setup-mode, a limit must be installed for the lower switch-
off position (e.g. windowsill) for the shutter to run against.
4.4. Selection table for settings:
Setup-mode/end positions in operation SEL Plus SES
4.4.1 Automatic setup-mode
bottom position, top stop/release
Stop at top
+ Stop at bottom
Stop at top
+ Stop at bottom
4.4.2 Manual setup-mode
bottom position, top position
Bottom position
+ top position
Bottom position
+ top position
4.4.3 Manual setup-mode
bottom position, top stop/release
Bottom position
+ top stop
Bottom position
+ top stop
Setting of the end positions
