177
AF characteristics
►
Overall device
►
Compander system Sennheiser HDX
EQ presets (switchable, act on
line and monitor outputs):
Preset 1: Flat
Preset 2: Low Cut –3 dB at 180 Hz
Preset 3: Low Cut / High Boost –3 dB at 180 Hz
+6 dB at 10 kHz
Preset 4: High Boost +6 dB at 10 kHz
Signal-to-noise ratio
(1 mV, peak deviation)
≥ 115 dBA
Total harmonic distortion (THD) ≤ 0.9 %
AF output voltage
(at peak deviation, 1 kHz AF)
6.3 mm jack socket
(unbalanced): +12 dBu
BNC socket
(balanced): +18 dBu
AF OUT setting range 48 dB in 3 dB steps
Temperature range -10 °C to +55 °C (14 °F to 131 °F)
Power supply 12 V DC
Power consumption 300 mA
Dimensions Approx. 202 x 212 x 43 mm
Weight approx. 980 g
