METIS M308 / M309 / M313 / M316 / M318 / M323 / H309 / H316 / H318 (12-pin)
Configuring the Pyrometer
25
6.3 Parameters / Settings
The table shows the adjustable parameters in order they appear on the pyrometer, detail description in
the next chapters.
Parameters
Meaning
Settings
MEASPARA.>
Measurement parameters
T90
Response time t
90
MIN / 01 ms10.0 s
STMODE
Storage mode peak picker:
peak picker off, with time clear (TIME, time settings
under CLR), extern cleared (EXT), automatic
cleared (AUTO), with trigger function (TRIG)
OFF / TIME / EXT. / AUTO /
TRIG
CLR
Clear time settings with STMODE set to time clear
(only if STMODE set to TIME)
OFF / 01 ms25.0 s
Ɛ1
Emissivity
0.0501.200
TR1
Transmittance
5.0100.0%
FF1
Spot size filling (Fill factor)
5.0100.0%
ZSC
ZeroScale temperature
(beginning of temp. sub range)
e.g. 0400°C
FSC
FullScale temperature
(end of temperature sub range)
e.g. 1300°C
TU
Temperature unit °C / °F
CELSIUS /FAHREN.
OUTPUTS>
Outputs
ANALOG>
Settings of analog output
A1
Analog output 1, current output
020 mA / 420 mA
A1TST
Test current
(10 mA at 0-20 mA, 12 mA at 4-20 mA)
OFF / 10 mA or 12 mA
A2
Analog output 2, current output
020 mA / 420 mA
A2OUT
Analog output 2 signal: off, measured tempera-
ture (TEMP), control output (CTR; only devices
with PID controller), device temperature (DTMP)
OFF / TEMP / CTR / DTMP
A2TST
Test current
(10 mA at 0-20 mA, 12 mA at 4-20 mA)
(not available if A2OUT is set to OFF)
OFF / 10 mA or 12 mA
INTERFACE>
Serial interface
RSTYP
Interface type (only M3)
232 / 485
BD
Baud rate
4.8115.2 kBd (RS232)
4.8921.6 kBd (RS485)
ADD
Address
0097
DELY
Delay
0020
FB.ADR
Fieldbus address (at Profibus devices)
00127
FB.MODE
Fieldbus mode (at Profibus- / Profinet devices)
0-2
MISC>
Miscellaneous settings
LG
Language
ENGLISH / DEUTSCH
N.PIN
Set (new) pin for push button lock
OFF / 00009999
FACT.SET
Reset to factory default settings
N / Y
INFO: These settings are available with the latest firmware. Missing settings in your device
can be added by updating the device firmware.
By connecting the power supply, the current firmware version is displayed for a few seconds, a
firmware update is possible with the Software SensorFlash (see 8).
