METIS M308 / M309 / M313 / M316 / M318 / M323 / H309 / H316 / H318 (12-pin)
Technical Data
54
Common Data
Temp. sub ranges
Any range adjustable within the temperature range (minimum span 50°C)
Emissivity ε
0.0501.200 (corresponds 5120% in 0.1% steps)
Transmission
0.0501.000
Fill factor spot size
0.0501.000
Analog output signal
2 programmable analog outputs 0 or 420 mA, switchable, max. load: 500 Ω
Resolution 0.0015% of the adjusted temperature sub range (16 Bit).
User selectable: Measuring temperature, device temperature or control output (if
equipped with a controller).
Outputs can be set individually, inside or outside the measuring range.
3 configurable
Inputs / outputs
Digital inputs (max. 3 inputs, protected against reverse polarity): laser targeting light
on/off, clearing of peak picker, controller start (when equipped with PID controller),
load pyrometer configuration, trigger input for start / stop of measured value record-
ing.
Digital outputs (max. 3 outputs, max. 50 mA, protected against short circuit): limit
switch, exceeding the beginning of temperature range (for material recognition), de-
vice ready after self-test, device over-temperature. When equipped with PID con-
troller: controller active, control process within limits, control process finished.
Analog input (020 mA, protected against reverse polarity and incorrect connec-
tion): analog adjustment of the emissivity, measuring distance at motor focus or
setpoint for PID controller (when equipped with PID controller).
Maximum value stor-
age / Peak picker
Automatic hold mode (built-in double storage) or manual time settings to clear or ex-
ternal clear (via configurable input)
Display
10-digit LED display (5 mm high) for temperature display or device settings
Resolution 0.1°C or 0.1°F
Parameter settings
Push buttons on the device, serial interface, PC software
SensorTools
or via self-
compiled communication program: Emissivity, transmission, fill factor, temperature sub
range, settings for peak picker, device address, baud rate, response time, selecting
analog outputs 0/420 mA, interface RS232/RS485 (selection on the device only),
°C/°F, language (English / German), measuring distance at motorized focus optics.
Power supply
24 V DC (1830 V DC), protected against reverse polarity
Isolation
Voltage supply, analog and digital output are galvanically isolated from each other
Sightings
(optional)
Through lens sighting with adjustable attenuation filter for eye protection of bright
targets
Laser targeting light (red, λ=650 nm, P< 1 mW, class II to IEC 60825-1)
Color CCD camera, field of view: ca. 3.6 x 2.7% of measuring distance
output signal: FBAS signal ca. 1 V
PP
, 75 Ω, CCIR, NTSC / PAL switchable,
resolution: NTSC: 720 x 480 pixel; PAL: 720 x 576 pixel
frame rate: NTSC: 60 Hz, PAL: 50 Hz
Storage temperature
-20 to 85°C (-4 to 185°F)
Relative humidity
Non-condensing conditions
Housing / protection
class
Aluminum, IP65 according to DIN 40 050 with connector
Weight
650 g
CE label
According to EU directives for electromagnetic immunity
9.1 Storage
Store packages under the following conditions:
Do not store outdoors
Store dry and dust-free
Do not exposed to corrosive media
Protect from direct sunlight
Avoid mechanical vibrations
Storage temperature: -20 to 85°C
Relative humidity: max. 95%,
no condensing conditions
