SensorTherm METIS H3 series - Composition of the Type Number

METIS M308 / M309 / M313 / M316 / M318 / M323 / H309 / H316 / H318 (12-pin)
Technical Data
56
9.3 Composition of the Type Number
The equipment version of the pyrometer is encoded in the 22-digit model number as follows
(Example type number M309 with 750–2500°C; laser targeting light, motorized focus, optics):
Digit
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
Expl.:
M
3
0
9
0
7
5
0
2
5
0
0
0
5
8
1
3
0
4
2
3
A
Digit
Indication of the various points
Code
Meaning / Example
01-02
Series M3
M3
Metis M3
Series H3
H3
Metis H3
03-04
Spectral range
08
0.855 – 0.905 µm
09
0.7–1.1 µm or 0.87 µm (Si)
13
1.27 µm (InGaS)
16
1.45–1.8 µm or 1.4 µm (InGaS)
18
1.65–2.1 µm (InGaS)
23
2–2.6 µm (InGaS)
05-08
Beginning of temperature range [°C]
0750
750°C
09-12
End of temperature range [°C]
2500
2500°C
13
Sighting
1
Laser targeting light
2
View finder
4
Color camera module
14
Serial interface
2
RS485
5
RS232 / RS485 (switchable)
3
Profinet integrated
4
Profibus integrated
15
Lens type
1
Fixed focus lens
2
Focusable optics
3
Fiber optics 0.2 mm Ø with focusable optics
4
Fiber optics 0.4 mm Ø with focusable optics
8
Motorized focus
7
Focusable optics (only M323)
B
Heavy duty stainless steel sensor head
for 0.2 mm fiber with OL25
C
Heavy duty stainless steel sensor head
for 0.4 mm fiber with OL25
16-17
Minimum response time
13
<1 ms
41
<40 µs
18
Configuration
0
Standard (12 pin connector, display, push
buttons, 3 digital inputs / outputs)
4
Standard + PID controller
19
Digital display
4
With display (12 pin connector)
20
Analog outputs
2
2 analog outputs
21
Digital input / digital output
3
3 digital inputs / outputs / 1 analog input
0–20 mA (with 12 pin connector)
22
Measuring distance / Optics
A
Optics A (depending on digit 15:
integrated optics or fiber optics)
B
Optics B
C
Optics C
D
Optics D
G
Optical fiber optics G
H
Optical fiber optics H
