32 Appendix C: Hardware Specifications
DUG-10009-01 RTM II FlexNet User Guide
C.3 Enclosure
The standard enclosure is painted steel. Features include:
• NEMA 1 rating
• Integrated mounting flanges
• Gray steel construction
• Dimensions: 5.6"H x 4"W x 1.7"D
• Optional NEMA 3R enclosure with 120 VAC - 12 VDC power supply; 11"H x 8.3"W x 3.3"D; 3 lbs
C.4 Operating Power
• 10-29 VDC, typically 170mA at 12 VDC, with a maximum of 0.6A (< 0.5 sec.)
C.5 Environmental Data
• Operating temperature Range: -40º to +70ºC
• Humidity: 0% to 95% noncondensing
• Surge Suppression: EN61000-4-4 and EN61000-4-5
• Radiated emissions: FCC Part 15 Class B, EN 55022
