150
Appendix F: MIDI Implementation
Sequential
Global Parameters Data Dump
Value Description
1111 0000
System Exclusive (SysEx)
0000 0001
DSI ID
0011 0001
Pro 3 ID
0000 1111
Main Parameter Data
0vvv vvvv
50 nibbles (LS then MS) for 25 Global parameters
1111 0111
End of Exclusive (EOX)
The Global Parameters Data Dump is not recognized when received. It is only
transmitted when requested. NRPN messages are used to change Globals.
Packed Data Format
Data is packed in 8 byte “packets”, with the MS bit stripped from 7 param-
eter bytes, and packed into an eighth byte, which is sent at the start of the 8
byte packet.
Example:
Input Data Packed MIDI data
1 A7 A6 A5 A4 A3 A2 A1 A0 1 00 G7 F7 E7 D7 C7 B7 A7
2 B7 B6 B5 B4 B3 B2 B1 B0 2 00 A6 A5 A4 A3 A2 A1 A0
3 C7 C6 C5 C4 C3 C2 C1 C0 3 00 B6 B5 B4 B3 B2 B1 B0
4 D7 D6 D5 D4 D3 D2 D1 D0 4 00 C6 C5 C4 C3 C2 C1 C0
5 E7 E6 E5 E4 E3 E2 E1 E0 5 00 D6 D5 D4 D3 D2 D1 D0
6 F7 F6 F5 F4 F3 F2 F1 F0 6 00 E6 E5 E4 E3 E2 E1 E0
7 G7 G6 G5 G4 G3 G2 G1 G0 7 00 F6 F5 F4 F3 F2 F1 F0
8 00 G6 G5 G4 G3 G2 G1 G0
