Serpent 710 - Step

13
H9
3x4mm
B12
3.5x9.5mm
Step 3.7
Step 3.8
Bag 09, 15
Bag 03,
U, B12
P7
2.5x16mm
B12
3.5x9.5mm
Step 3.9
U6
6x13mm
1
2
3
2
6
1
1
2
5
4
Assemble both rear upper arms using
the indicated steps.
Roughen metal plates with
sandpaper before gluing.
Press pins into bulkhead until ends
are flush with outer edge.
R3
3mm
U6
6x13mm
H9
U6
R3
P7
B12
B12
B12
B12
B12
U6
