Using the manual
Each step contains a variety of numbers, lines, and symbols. The numbers represent the order in which
the parts should be assembled. The lines and symbols are described below.
Line/Symbol
Description
Assembly path of one item into another.
Group of items (within lines) should be assembled first.
Direction the item should be moved.
Glue one item to another.
Press/Insert one item into another.
Gap between two items.
Apply graphite grease (GR), threadlock (TL), CA glue (CA) or Serpent’s
One-way Lube (OW). (items not included).
myTSN.com
The printed instruction manual included with your
Serpent 710 kit is very complete, though due to
continuous product development, more up-to-date
information is provided at our myTSN.com web
portal. This state-of-the-art R/C technology portal
is where Serpent racers from all over the world
meet and exchange their ideas, and share useful
information and experiences about their Serpent
cars.
All information about the Serpent 710 is acces-
sible from the Serpent 710 product page on
myTSN.com. You can access this page by going to
the Products section, then search for the ‘Serpent
710’ product name.
From the Serpent 710 product page you will find
the very latest information about your Serpent 710:
reports by team drivers and other experts, tips and
tricks, FAQ, forums, setups, image gallery, down-
loadable files, and even streaming video of the
Serpent 710 on how to further improve the car. The
latest version of the instruction manual (including
team and racer tips, and part lists and option lists)
will be made available as downloadable PDF-files
and online viewable pages under ‘i-Manual’.
So be sure to visit myTSN.com and the Serpent
710 page. There is a world of up-to-date informa-
tion about your Serpent 710 waiting for you, and it
is just a few mouse clicks away! If you are not yet
a member of myTSN, we strongly recommend that
you sign up immediately so you can experience and
enjoy an even wider range of services from Serpent
and other myTSN partners.
www.myTSN.com/Serpent710
