19
E11
3x8mm
5.0 Bodymount Assembly
E12
3x10mm
Step 5.1
Bag 14,
29, E11
E10
3x6mm
Step 5.2
1
1
2
2
3
1
2
Upper shock default mounting
position
Lower shock default mounting
position
E29
3x18mm
H12
3x10mm
H12
E11
E11
E12
E29
E12
E29
H12
E10
Bag E10
