Serpent 710 - Steering Block Assembly

7
E12
3x10mm
U13
12x18mm
E10
3x6mm
Step 1.9
Step 1.10
Step 1.11
Bag E10,
U, 19
3
1
1
2
4
2
1
1
5
3
Change the position of BOTH
eccentric hubs to adjust front
belt tension. Both hubs should
have the same position.
Assemble both steering blocks
using the indicated steps. Left
steering block shown.
Do not overtighten alu plugs. Pivotballs should
move freely without binding or excessive play.
Assemble both steering
blocks as shown.
IMPORTANT!
Ensure the front suspension
moves up and down freely without binding.
17mm
16.5mm
Looser
Loose
Tighter
Default
Bag U, E12,
07, 13
H8
3x3mm
P1
2x10mm
U11
10x15mm
E12
E12
E12
E12
U13
U13
U11
P1
U11
H8
E10
Front
Rear
