11
STEp 16
STEp 17
M3x6
M3x8
12x18x4
12x18x4
1
2
3
2
12x18x4
REARBELTTENSION
Use the central slot as
starting position.
M3x8
M3x6
17.1
17.2
M3x10
6x10x3
Flanged
6x10x3
Flanged
2
1
6X10X3 Flanged
5x7
M3x10
5x7
bag 3
