Serpent 750 EVO - Radio Assembly; Servos Wire Diagram

25
RaDIO aSSEmbly
STEp 39
M3x10
M3x16
M3x10
1
2
Note the position of the steering servo “ears”. Each
one is in one side of the radio box.
M3x10 M3x16
STEp 40
M3x6
M3x6
M2x6
M2x6
SERVO’SWIREDIAGRAM
M2x6
M3x6
bag 10
