Serpent 750 EVO - Rear Reactive Steering System

13
STEp 20
20.1
20.2 20.3
10x15x4
10x15x4
2x10
2x10
M3x3
M3x6
10x15x4
2x10
M3x3
1
1
2
3
4
11 mm
REARTOE-IN
LINKLENGTH
bag 4
M3x6
M3x6
M3x6
REARREACTIVESTEERINGSYSTEM
Serpent 750 EVO introduce the Active rear toe-in. It brings a
new dimension to setup changing the toe-in characteristics
of the rear tires under rolling effect. It allows to run less static
toe-in and still have a good traction coming out of the corner.
Serpent RRS System brings the possibility to fully adjust the
amount of toe-change over the suspension travel even having
the possibility of no toe-in change in droop and still have a
toe-in raise under compression.
Toe in will not
change over the
suspension travel.
Toe in will decrease under
aceleration (compression)
and will increase under
braking (extension).
Toe in will increase under
aceleration (compression)
and will drecrease under
braking (extension).
