Serpent 750 EVO - Shock Length Measurement

36
STEp 61
61.3
61.1
SHOCKSLENGTH:
Measure the shock length fully extended.
14.5
mm
Assemble the spring and
spring-cup (align correctly)
to complete the shock.
Push the shock top
and the membrane
into the shock cap.
1- Fill up with sillicone oil
fully using the silicone
oil supplied in the kit.
For the correct cst value
please check the default
setupsheet.
2- Extend the shockrod
fully
3- Move the shockrod
slowly up and down
to let ALL air bubbles
escape.
4- Close top only 3/4.
1-Bleed: push the
shockrod all the way
in slowly, to allow
excessive oil to
escape.
2- Close the shock
cap completely.
62.2
STEp 62
