Serpent 950 - Page 5

Step 1.4
Shock Assembly
Y4
3.1x1.6mm
Step 1.5
Shock Assembly
Step 1.6
Shock Assembly
5
1
2
Fill the cylinder with shock oil, with the piston in the
bottom position.
Bleeding sequence: Let the oil settle and allow the air
to escape. Slowly move the piston up and down until
no more bubbles appear.
Hold the shock rod firm using plyers, grip on the
part where the thread begins, do not damage the
shock rod. Turn the ball-joint on to the shock rod.
