AL-2020/2035/2040/2050/2060 SIMULATION, TROUBLE CODES 10 - 14
26 43 Side void setup [Function]
When this simulation is executed, the currently set code of the side void quantity is displayed
(initial display), and the set data are saved. (Setting range: 0 – 10, Default: 4 (= One side
2.0mm))
* When the adjustment value is increased by 1, the side void is changed as follows:
Side void adjustment: The side void is increased by 0.5mm. (The side void of "Set value x
0.5mm" is made.)
[Operation]
The operation is similar to simulation 09-04.
54 γ life correction setting [Function]
Used to set the γ life correction.
When this simulation is executed, the current set code number is displayed.
Enter the desired code number and press [OK]/[START] key to save the setting.
(Setting range: 0 – 1, default: 1)
[Operation]
The operation is similar to simulation 26-02.
62 Energy-save mode copy
lamp setup
[Function]
Used to set half-ON /OFF of the copy lamp in the pre-heat mode.
When this simulation is executed, the current set code number is displayed. Enter the desired
code number and press [OK]/[START] key to save the setting.
[Operation]
The operation is similar to simulation 26-02.
30 01 Paper sensor status display [Function]
The paper sensor status is displayed on the LCD/LED.
∗ Since the manual paper feed sensor is a single bypass sensor, its status is not displayed.
∗ The width sensor is available only in the FAX models.
[Operation] (AL-2050/2060)
Main
code
Sub
code
Contents Details of function/operation
Code Setting Remark
00 mm
10.5 mm
21.0 mm
31.5 mm
4 2.0 mm Default
52.5 mm
63.0 mm
73.5 mm
84.0 mm
94.5 mm
10 5.5 mm
Code number Setting Display item Remark
0OFFOFF
1 ON ON Default
Code number Setting Display item Remark
0Copy lamp OFF OFF
1 Copy lamp half-ON ON Default
Sensor
Display item
(AL-2050/2060)
Display lamp
(AL-2020/2035/2040)
Paper exit sensor POD Photoconductor cartridge replacement lamp
Paper entry sensor PPD1 Developer cartridge replacement lamp
Duplex sensor PPD2 JAM lamp
New drum cartridge sensor DRST Zoom lamp
1) Initial display 2) When sensor ON
30-01 P-SENSOR
30-01 POD PD1 PD2
PPD1 PPD2 DRST
