AL-2020/2035/2040/2050/2060 SPECIFICATIONS 2 - 2
3. Copy performance
*1: The first-copy time is measured after the power save indicator turns off following power on, using the document glass with the polygon rotat-
ing in the copy ready state and "Selection of copy start state" set to ON in the user programs (A4 (8-1/2" x 11"), paper fed from paper tray).
The first-copy time may vary depending on machine operating conditions and ambient conditions such as temperature.
Image forming Photoconductor Type OPC (30ø)
Life 18k
Charger Charging system Saw-tooth charging with a grid, / (-) scorotron discharge
Transfer system (+) DC corotron system
Separation system (-) DC corotron system
Developing Developing system Dry, 2-component magnetic brush development system
Cleaning Cleaning system Counter blade system (Counter to rotation)
Fusing section Fusing system Heat roller system
Upper heat roller Type Teflon roller
Lower heat roller Type Silicon rubber roller
Heater lamp Type Halogen lamp
Voltage 120V / 220 - 240V
Power consumption 800W
Electrical section Power source Voltage 120V / 220 - 240V
Frequency Common use for 50 and 60Hz
Power consumption Max. Less than 1000W
Average (during copying) 350Wh/H or less (AL-2020/2035/2040)
380Wh/H or less (AL-2050/2060)
Average (stand-by) 80Wh/H or less
Pre-heat mode 25Wh/H or less (AL-2020/2035/2040)
28Wh/H or less (AL-2050/2060)
Auto power shut-off mode 8.8W or less (AL-2020/2035/2040)
12.5W or less (AL-2050/2060)
Section, item Details AL-2020/2035/2040/2050/2060
Copy magnification Fixed magnification
ratios
4 Reduction + 3 Enlargement
(AB system: 25, 50, 70, 86, 100, 141, 200, 400%)
(Inch system: 25, 50, 64, 78, 100, 129, 200, 400%)
Zooming magnification
ratios
25 - 400% (376 steps in 1% increments)
50 - 200% when using SPF/RSPF (151 steps in 1% increments)
Manual steps (manual, photo) 5 steps
Copy speed (CPM) First-copy time *1
(Approximately)
AL-2020/2035/2040:
8.0 seconds (When user program 24 is set to OFF)
10.7 seconds
(paper: A4 (8-1/2" x 11"), exposure mode: AUTO, copy ratio: 100%)
AL-2050/2060:
8.0 seconds
AB system
A4 (Landscape)
Same size 20
AB system
B5 (Landscape)
Same size 20
Inch system
8-1/2" x 11" (Landscape)
Same size 20
Max. continuous copy quantity 99
Void Void area Leading edge 1 - 4mm
Trailing edge 4mm or less
Side edge void area 0.5mm or more (per side)
4.5mm or less (total of both sides)
Image loss Leading edge same size: 3.0mm or less (OC) / 4mm or less (SPF/RSPF)
Enlarge: 1.5mm or less (OC) / 3mm or less (SPF/RSPF)
Reduction (50%): 6.0mm or less (OC) / 8mm or less (SPF/RSPF)
Warm-up time 0 sec. Immediately the ready lamp is lit.
Power save mode reset time 0 sec. Immediately the ready lamp is lit.
Paper jam recovery time 0 sec.
∗ Jam recovery condition: Recovery time from 60 sec of door open.
Section, item Details
