AL-2020/2035/2040/2050/2060 FAX SOFT SWITCH 12 - 1
[12] FAX SOFT SWITCH
1. FAX soft switch setting change quick reference table
Large item Middle item Switch content Key operator Soft SW No. Usage
Dialing Remote machine call
disable
Pause time None SW 5-5 – 8 When dialing disable/when error dialing
Dial call signal User program SW 48-1, 2 When dialing disable
DTMF-related item None SW 51-1 – 5 When dialing disable in PBX (private branch
exchange/Fax service, etc.)
None SW 53-5 – 8 When dialing disable in PBX (private branch
exchange/Fax service, etc.)
None SW 39-4 – 8 When dialing disable in PBX (private branch
exchange/Fax service, etc.)
Pulse (10PPS) None SW 67-1 – 4 When pulse dialing disable
Signal detection Busy tone detection None SW 7-3 When busy tone detection disable
Busy tone detection None SW 51-7, 8 When busy tone error is detected
Dial tone detection None SW 7-2
Redial In case of an error Resend interval User program SW 4-1 – 4 When send errors occur frequently
(For the New Zealand models, tough it is set
to 0, recall is performed in an interval of
1min.)
In case of an error Number of times of resend User program SW 40-1 – 8
When busy Resend interval User program SW 4-5 – 8 Whey busy occurs frequently
When busy Number of times of resend User program SW 41-1 – 8
Arrival (Call-in) When CI detection
disable
CI detection None SW 12-6, 7 No call-in
CI signal OFF detection
time
None SW 55-1 – 7 No call-in
External
telephone
Setting of an external
telephone connected
Yes/No None SW 47-2 When an external telephone is connected
Remote switch
number
Entry of a 2-digit number User program SW 2-5 – 8 When remote switch is erroneously
detected
Remote switch
setting
Yes/No User program SW 8-5 When remote switch is erroneously
detected
Communication General Send level None SW 15-4 – 8 When the remote machine cannot receive
signals in a proper level.
JBIG mode None SW 17-4, 8 When an error occurs in the JBIG mode
SG3 V34 mode function setup None SW 43-1 When SG3 communication error occurs
frequently
V34 symbol rate None SW 43-4 – 6 When SG3 communication error occurs
frequently
Transmission G3/SG3 DIS reception check None SW 6-8 When an error occurs in phase B
Line equalizer None SW 59-5 – 8 Setting is made referring to the distance
from the station when a communication
trouble occurs.
SG3 V34 send speed None SW 44-1 – 4 When an error occurs in the SG3
communication.
Manual send V34 None SW 42-8 When an error occurs in the SG3
communication in FAX service, etc.
G3 Modem send speed None SW 16-1 – 4 To specified/unspecified destination
RTN reception error None SW 52-5 When judged as “OK” though RTN is
received
Reception G3/SG3 CSI transmission None SW 6-3
Maximum reception length None SW 7-6 When a document of 1m or longer is
received
SG3 V34 reception speed None SW 44-5 – 8 When fall-down occurs frequently in the
SG3 communication
G3 Countermeasure against
echo in reception
None SW 6-4 When an error occurs in phase B in
reception
Modem speed in reception None SW 16-5, 6 When the line quality is poor and a fall-back
or an error occurs
EYE-Q check only None SW 72-1 Change in the detection method of training
error
Reception print Paper selection Automatic reduction print User program SW 24-8 When reduction print is not made
Index Index print setup User program SW 32-6 When an index is attached to the reception
data
