AL-2020/2035/2040/2050/2060 SIMULATION, TROUBLE CODES 10 - 44
<Communication result codes>
(Note) For error codes 16 – 31, V.34 mode communication.
<Error codes 1>
Error codes 1 are fixed to “00”.
<Error codes 2>
Error
code
Final reception signal
(Transmitting side)
Final reception signal
(Receiving side)
0 Abnormal signal Abnormal signal
1 NSF, DIS NSS, DCS
2 CFR NSC, DTC
3FTT EOP
4MCF EOM
5 PIP, PIN MPS
6RTN, RTP PRI-Q
7 No signal DCN
8 PPR PPS-EOP
9PPS-EOM
10 PPS-MPS, PPS-NULL
11 RNR RR
12 CTR CTC
13 ERR EOR-Q
14 PPS-PRI-Q
15
16 Abnormal signal Abnormal signal
17 NSF, DIS NSS, DCS
18 CFR NSC, DTC
19 FTT PPS-EOP
20 MCF PPS-EOM
21 PIP, PIN PPS-MPS, PPS-NULL
22 RTN, RTP PRI-Q
23 No signal DCN
24 PPR
25 RNR RR
26 CTR CTC
27 ERR EOR-Q
28 PPS-PRI-Q
29 V.8 Phase-1 V.8 Phase-1
30 V.8 Phase-2 V.8 Phase-2
31 V.8 Phase-3 V.8 Phase-3
Error
codes 2
Content of communication interruption
Transmission/
Reception
01 Transmission length over Transmission
02 EOL time over Reception
03 Carrier detection time up Reception
04 Polarity reversion detection (in phase C) Transmission/
Reception
05 8 min over (in phase C) Transmission
06 Memory image decoding error Reception
07 Memory image decoding error Transmission
08 Time up between frames in phase C Transmission/
Reception
10 Communication request NG Reception
11 Polarity reversion detection Reception
12 Invalid command reception Reception
13 Time over (1min timer/6sec timer) Reception
14 PUT error Reception
15 Time out occurrence during shift from
Primary to Control in V.34 mode
Reception
20 Polarity reversion detection Transmission
21 Invalid command reception Transmission
22 Fall back retry number over Transmission
23 Resend over of retry number Transmission
24 Time over (T5 timer) Transmission
25 Time over (T5 timer) in V.34 mode Transmission
26 Time out occurrence during shift from
Primary to Control in V.34 mode
Transmission
30 Communication error due to
communication abnormality between
FAX_SUB and FAX_MAIN
Transmission/
Reception
