AL-2020/2035/2040/2050/2060 FAX SOFT SWITCH 12 - 10
S
W
41
1 Number of times of recall
in busy
Binary input
2 times
0 Refer to User program
“RECALL TIMES
(BUSY)”.
When a value outside
the set range is set,
the initial value is set.
2 Bit No.
Set range
12345678
0 to 10 times
0
3 0
4 0
5 0
6 0
7 1
8 0
S
W
42
1 Inhibited to use 0
2 FAX receive auto select by
CNG detection
1: Allow 0: Inhibit
Allow 1
Refer to User program
“FAX SIGNAL AUTO
RECEIVE”.
3 Auto receive select in
answering telephone
connection mode
1: Allow 0: Inhibit
Inhibit 0
Refer to Main menu
“AM MODE”.
4 Inhibited to use 1
5 0
6 0
7 0
8 V.34 mode function in
manual communication
1: ON 0: OFF
ON 1
S
W
43
1 V.34 mode function 1: ON 0: OFF ON 1
2 Inhibited to use 0
3 1
4 V.34 receive symbol
speed mask
Bit No. 4 5 6
3429
1
When a value outside
the set range is set,
the initial value is set.
2400 0 0 0
2743 0 0 1
5 2800 0 1 0
0
3000 0 1 1
6 3200 1 0 0
1
3429 1 0 1
7 Inhibited to use 0
8 0
S
W
44
1 V.34 primary channel send
speed
Binary input
33600bps
1
2 Bit No.
Send speed =
2400 (bps) x N
1234
When N = 0, 2400bps.
When N = 15, 33600bps.
1
3 1
4 0
5 V.34 primary channel
receive speed
Binary input
33600bps
1
6 Bit No.
Receive speed =
2400 (bps) x N
5678
When N = 0, 2400bps.
When N = 15, 33600bps.
1
7 1
8 0
S
W
45
1 FAST mode 1: Yes 0: No No 0
2 Sequence of year/month/
day in LCD, report, and
sender record
Bit No. 2 3
Day/Month/Year
1
Refer to User program
“DATE&TIME
FORMAT SET”.
When a value outside
the set range is set,
the initial value is set.
Year/Month/Day 0 0
Month/Day/Year 0 1
3 Day/Month/Year 1 0
0
4 Time display format 1: am/pm 0: 24H
24H 0
Refer to User program
“DATE&TIME
FORMAT SET”.
5 Scan effective image area
main scan right edge
image loss (RSPF)
Binary input
96 dots
0
6 Bit No.
Set range
5678
0 to 360 dots
24 dots interval
1
7 0
8 0
SW
NO.
Data
No.
Item Switch selection and contents of functions Initial value Remark
