11
2
Installation
REMOVING PROTECTIVE PACKING MATERIALS
1
Remove the screw from the left side of the copier by rotating it in the direction indicated
by the arrow. Remove protective material .
The screw must be used if the copier has to be moved. (p.45) Store the screw
inside the front cover.
Do not remove with the front cover closed.
a
b
2
Remove the tape .
3
Push gently on both sides of the front cover to open the cover.
4
Store the screw which has been removed in step 1 at the right side inside the front
cover.
To Next Page
