6
Preparation
• Before attaching (or detaching) the stand, unplug the AC cord from the AC INPUT terminal.
• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being
damaged.
CAUTION
• Attach the stand in the correct direction.
• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
Attaching the stand
1
3
1
Insert the stand into the openings on the
bottom of the TV.
2
Insert and tighten the 4 screws into the 4
holes on the rear of the TV.
Hex key
Screw
Soft
cushion
NOTE
• To detach the stand, perform the steps in reverse order.
2
Hex
key
Screw
Attach the supporting post for the stand unit
onto the base as shown below.
Confi rm the screws supplied with the TV.
Screws (
g
4)
(used in step 3)
Screws (
g
5)
(used in step 2)
32D33X_en_b.indd 632D33X_en_b.indd 6 2008-1-24 14:52:292008-1-24 14:52:29
To Next Page
