Appendix
NOTE
• To attach the stand, perform the above steps in reverse
order.
• As the TV is very heavy, be careful when moving it.
Mounting the TV on the wall
Removing the stand
For wall mounting with the optional bracket (AN-37AG2+AN-37P30 or AN-52AG4) remove the stand.
Before setting TV on the wall.
• Remove the connected cables (DVD, VCR, etc) from the terminals.
• Detach the four caps at the 4 locations on the rear of the TV.
62
1
2
2
1
3
1
Unfasten the 4 screws.
2
Remove the supporting post from the TV.
Remove the screws at the 4 locations on the rear of
the TV.
Lay the TV fl at.
• Spread a cushion over the base area to lay the TV on.
Unfasten the screw on the rear of the TV.
4
2
1
1
Pinch the portion at
1
.
2
Pull out the portion at
2
.
