Sharp AR-5625 - Maintenance Parts Replacement Schedule

AR-M256/M257/M258/M316/M317/M318/5625/5631 CONSUMABLE PARTS 4 - 2
2. Maintenance parts list
A. SDSCA/ SECL/ LAG (AR-M257/ M317)
∗ The other maintenance parts than the above are supplied as service parts.
B. SEEG/ SUK/ SCA/ SCNZ/ SEA/ SEES/ SEZ/ SEIS/ SEB/ SEN/ SEF/ SMEF/ Russia/ Special country
(AR-M256/ M316, AR-5625/ 5631)
∗ The other maintenance parts than the above are supplied as service parts.
No. Item Content Life
Model
name
Remarks
1 Upper heat roller kit Upper heat roller
Fuser gear
Upper heat roller bearing
Upper cleaning pad
Fusing separation pawl (upper)
×1
×1
×2
×1
×4
150K AR-310UH
2 Lower heat roller kit Lower heat roller
Fusing separation pawl (lower)
Fuser bearing (lower)
×1
×4
×2
300K AR-310LH
3 150K maintenance
kit
Drum separation pawl unit
Transfer roller unit
×2
×1
150K AR-310KA1
4 MC unit MC unit ×10 25cpm: 75K (×10)
31cpm: 100K (×10)
AR-310MC AR-310MC = AR-310NC ×10
The order places an order in AR-310MC.
Addition of Sterling.
5 Cleaner blade Cleaner blade ×10 25cpm: 75K (×10)
31cpm: 100K (×10)
AR-270CB AR-270CB = AR-270BL ×10
The order places an order in AR-270CB.
6 Drum frame unit Drum frame unit ×1 25cpm: 225K
31cpm: 300K
AR-310DU
∗ The life of the toner reception seat attached to
the drum frame is 225K (25cpm)/ 300K
(31cpm), and it can be used up to 3 times.
(Supplied as a drum frame unit.)
∗ Drum frame unit contains all the drum unit
parts excluding Drum and Drum fixing plate.
7 Transfer roller unit Transfer roller unit ×1 150K AR-310TX
8 Paper feed roller kit Paper feed roller kit ×1 100K AR-310IR
9 Fusing unit Fusing unit (120V heater lamp) ×1 150K AR-310FU
10 Staple cartridge Staple cartridge ×3 3000 staples ×3 AR-SC1 For AR-FN5A (For 30 sheets staple)
Common with the cartridge for FN4
11 Staple cartridge Staple cartridge ×3 5000 staples ×3 AR-SC2 For AR-F14N (For 50 sheets staple)
Common with the cartridge for FN7
No. Item Content Life
Model
name
Remarks
1 Upper heat roller kit Upper heat roller
Fuser gear
Upper heat roller bearing
Upper cleaning pad
Fusing separation pawl (upper)
×1
×1
×2
×1
×4
150K AR-310UH
2 Lower heat roller kit Lower heat roller
Fusing separation pawl (lower)
Fuser bearing (lower)
×1
×4
×2
300K AR-310LH
3 150K maintenance
kit
Drum separation pawl unit
Transfer roller unit
DV blade
DV side sheet N
×2
×1
×1
×2
150K AR-310KA
4 MC unit MC unit ×10 25cpm: 75K (×10)
31cpm: 100K (×10)
AR-310MC AR-310MC = AR-310NC ×10
The order places an order in AR-310MC.
Addition of Sterling.
5 Cleaner blade Cleaner blade ×10 25cpm: 75K (×10)
31cpm: 100K (×10)
AR-270CB AR-270CB = AR-270BL ×10
The order places an order in AR-270CB.
6 Drum frame unit Drum frame unit ×1 25cpm: 225K
31cpm: 300K
AR-310DU
∗ The life of the toner reception seat attached to
the drum frame is 225K (25cpm)/ 300K
(31cpm), and it can be used up to 3 times.
(Supplied as a drum frame unit.)
∗ Drum frame unit contains all the drum unit
parts excluding Drum and Drum fixing plate.
7 Transfer roller unit Transfer roller unit ×1 150K AR-310TX
8 Staple cartridge Staple cartridge ×3 3000 staples ×3 AR-SC1 For AR-FN5A (For 30 sheets staple)
Common with the cartridge for FN4
9 Staple cartridge Staple cartridge ×3 5000 staples ×3 AR-SC2 For AR-F14N (For 50 sheets staple)
Common with the cartridge for FN7
