Sharp LC-32A28L User Manual

LC-32A28L, LC-42A48L
56
18
ERROR
O Error status Open-drain output
19
RESET
I Reset, low active Schmitt trigger TTL input buffer
20 SA0 I I
2
C select address 0 Schmitt trigger TTL input buffer
21 SA1 I I
2
C select address 1 Schmitt trigger TTL input buffer
22 N.C
23 N.C
24 SCL I I
2
C serial clock input Schmitt trigger TTL input buffer
25 SDA I/O I
2
C bi-directional serial data Schmitt trigger TTL input buffer
26 DGND P Digital Ground
27 DVDD P Digital Power
28 N.C
29 N.C
30 N.C
31 N.C
32 N.C
33 N.C
34 N.C
35 N.C
36 N.C.
37 N.C.
38 VDDRA P Supply for right channel A
39 RA O Right channel output A
40 GNDR P Ground for right channel
41 RB O Right channel output B
42 VDDRB P Supply for right channel B
43 VDDLB P Supply for left channel B
44 LB O Left channel output B
45 GNDL P Ground for left channel
46 LA O Left channel output A
47 VDDLA P Supply for left channel A
48 N.C.
