Sharp LC-32L400M Service Manual

LC-32L400M
4 – 3
3. Removing of the MAIN Unit and POWER SUB Unit
1. Remove the 2 lock shafts [1], 2 lock shafts [2], 2 lock screws [3] and detach the MAIN Unit.
2. Remove the 5 lock screws [4] and detach the POWER SUB Unit.
MAIN Unit
POWER SUB Unit
4
3
1
2
