LC-32L400M
6 – 1
LC-32L400M
Service Manual
CHAPTER 6. TROUBLESHOOTING TABLE
[1] TROUBLESHOOTING TABLE
No power (front LED failure to light up) or no startup (front LED failure to turn from red to green)
Is the AC cord connector tightly connected to the set? NO Reconnect the AC cord tightly and turn on the power again.
YES
Is the output voltage at pin (7), (8), (9) and (10) of P5201 (13.0V
line) as specified?
NO Replace the power unit.
YES
Are the wire harnesses and other cables properly connected in
the set?
NO Reconnect the wire harnesses and other cables properly in the
set.
YES
Is there the AC_DET and PNL_ON signal input at pins (14) and
(1) of P5201?
NO Check the AC_DET signal line PNL_ON signal line.
YES
Are the DC/DC converter outputs and the output voltages along
the control lines as specified?
NO Check the DC/DC converters and the control lines. Replace
defective parts as required.
1) B1.26V (IC9606)
2) D2.6V (IC9603)
3) STB+3.3V (IC9602)
4) D3.3V (IC9653)
5) B5V (IC9652)
To Next Page
