Sharp LC-32L400M Service Manual

LC-32L400M
4 – 6
6. Removing of the Top Bracket, Bottom Bracket and LCD Panel Module
1. Remove the 4 lock screws [1].
2. Remove the 4 lock screws [2] and detach the Top Bracket, Bottom Bracket.
3. Remove the 2 lock screws [3] and detach the LCD Panel Module.
2
1
3
Bottom Bracket
LCD Panel Module
Top Bracket
2
1
3
