PARTS GUIDE
CONTENTS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-32L400M
No. S40F6LC32L40M
Note:
The reference numbers on the PWB are arranged
in alphabetical order.
LCD COLOUR TELEVISION
LC-32L400M
MODEL
PartsGuide
[1] PRINTED WIRING BOARD ASSEMBLIES
[2] LCD PANEL
[3] DUNTKF537FM02 (MAIN Unit)
[4] DUNTKF538FM02 (POWER SUB Unit)
[5] DUNTKF539FM02 (R/C, LED Unit)
[6] CABINET AND MECHANICAL PARTS
[7] LCD MODULE Assembly
[8] SUPPLIED ACCESSORIES
[9] PACKING PARTS
(NOT REPLACEMENT ITEM)
[10] SERVICE JIGS (USE FOR SERVICING)
