Sharp LC-32L400M Service Manual

LC-32L400M
8
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
C7312 VCEA0A1HW105M+ AB J Capacitor, 1 50V Electrolytic
C7313 VCEA0A1HW475M+ AB J Capacitor, 4.7 50V Electrolytic
C7314 VCKYCY1EB104KY AB J Capacitor, 0.1 25V Ceramic
C7318 VCKYPA2HB102K+ AA J Capacitor, 1000p 500V Ceramic
C7319 VCKYPA2HB102K+ AA J Capacitor, 1000p 500V Ceramic
C7403 VCEA0A1HW107M+ AB J Capacitor, 100 50V Electrolytic
C7404 VCKYTV1EB105KY AB J Capacitor, 1 25V Ceramic
!
D7001 RH-DX0477CEZZ AF J Diode, D5SB60
D7202 VHD1SS244//-1Y AB J Diode, 1SS244T-72
D7203 RH-EX0648GEZZY AB J Zener Diode, MTZJT-7216A
D7205 RH-DX0321CEZZY AC J Diode, EG01CV1
D7211 VHDCUS02TE+-1Y AB J Diode, CUS02(TE85L,Q)
D7212 RH-DXA095WJZZY AB J Diode, 1N4004G
D7301 VHDHSS4148+-1Y AA J Diode, HSS4148TA-E
D7302 VHDHSS4148+-1Y AA J Diode, HSS4148TA-E
D7303 VHDHSS4148+-1Y AA J Diode, HSS4148TA-E
D7304 VHDHSS4148+-1Y AA J Diode, HSS4148TA-E
D7305 RH-EX0640GEZZY AA J Zener Diode, MTZJT-7212B
D7311 RH-DXA144WJQZ AE J Diode, FMEN-220B
D7312 RH-DXA144WJQZ AE J Diode, FMEN-220B
!
F7001 QFS-CA022WJZZ AC J Fuse, 5A 250V
!
F7002 QFS-CA022WJZZ AC J Fuse, 5A 250V
FB7202 RBLN-0020CEZZ+ AB J Ferrite Core
FB7205 RBLN-0020CEZZ+ AB J Ferrite Core
FB7305 RBLN-0020CEZZ+ AB J Ferrite Core
FB7306 RBLN-0020CEZZ+ AB J Ferrite Core
FH7001 QFSHDA008WJZZ+ AB J Fuse Holder
FH7002 QFSHDA008WJZZ+ AB J Fuse Holder
FH7003 QFSHDA008WJZZ+ AB J Fuse Holder
FH7004 QFSHDA008WJZZ+ AB J Fuse Holder
HM7001 LX-GZ3001PEZZ AB J Screw
HM7002 LX-GZ3001PEZZ AB J Screw
HM7009 LX-GZ3002PEZZ AB J Screw
HM7010 LX-GZ3002PEZZ AB J Screw
HM7201 LX-GZ3001PEZZ AB J Screw
HM7301 LX-GZ3001PEZZ AB J Screw
IC7201 VHIFA5571++-1Y AG N V IC, FA5571N-D1
!
IC7241 RH-FXA014WJZZ AC J IC, TLP781F(D4-GRL,F)
IC7301 VHIKIA431A+-1+ AC J IC, KIA431A-AT/P
J5503 QJAKFA068WJQZ AD J Jack
J5508 QJAKGA164WJQZ AD N V Jack
J5509 QJAKGA131WJZZ AG J Jack
J5510 QJAKGA164WJQZ AD N V Jack
J5511 QSOCDA035WJZZ AD J Socket
!
L7002 RCILFA361WJQZ AF N V Coil
L7301 RCILPA703WJZZ+ AD V Coil
L7302 RCILPA707WJZZ+ AD J Coil
L7303 RCILPA707WJZZ+ AD J Coil
P5201 QCNCMA012WJZZ AD J Connector
P5202 QCNCMA012WJZZ AD J Connector
P5203 QCNCMA012WJZZ AD J Connector
P5204 QPLGNA053WJZZ AF J Plug
P7001 QPLGN0269GEZZ AB J Plug
Q7201 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q7202 VSTK13A60D+-1 AK N V Transistor, TK13A60D(LBS1SP,Q)
Q7303 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q7304 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q7309 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q7401 VSRSS075P03-1Y AF J Transistor, RSS075P03TB
Q7402 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q7403 VS2SA1271-Y-1+ AC J Transistor, 2SA1271Y-AT/P
R901 VRS-CY1JF822JY AA J Resistor, 8.2k 1/16W Metal Oxide
R902 VRS-CY1JF123JY AA J Resistor, 12k 1/16W Metal Oxide
R903 VRS-CY1JF822JY AA J Resistor, 8.2k 1/16W Metal Oxide
R904 VRS-CY1JF123JY AA J Resistor, 12k 1/16W Metal Oxide
R5203 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R5206 VRS-CY1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R5207 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R5501 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R5502 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R5503 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R5504 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R5505 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R5506 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R5507 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R5508 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R5509 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R5515 VRS-CY1JF123JY AA J
Resistor, 12k 1/16W Metal Oxide
R5516 VRS-CY1JF183JY AA J Resistor, 18k 1/16W Metal Oxide
R5517 VRS-CY1JF123JY AA J Resistor, 12k 1/16W Metal Oxide
R5519 VRS-CY1JF183JY AA J Resistor, 18k 1/16W Metal Oxide
R5521 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R5523 VRS-TQ2EF750JY AA J Resistor, 75 1/4W Metal Oxide
R5529 VRS-CY1JF123JY AA J Resistor, 12k 1/16W Metal Oxide
R5530 VRS-CY1JF123JY AA J Resistor, 12k 1/16W Metal Oxide
[4] DUNTKF538FM02 (POWER SUB Unit)
