Sharp LC-32LE600E Service Manual

LC-32/40/46LE600E/RU/S (1st Edition)
14
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R9624 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9626 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9627 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R9628 VRS-CZ1JF473FY AA J Resistor 47k 1/16W Metal Oxide
R9629 VRS-CZ1JF153FY AA J Resistor 15k 1/16W Metal Oxide
R9630 VRS-CZ1JF153FY AA J Resistor 15k 1/16W Metal Oxide
R9631 VRS-CZ1JF123FY AA J Resistor 12k 1/16W Metal Oxide
R9632 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R9633 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9634 VRS-CZ1JF3R9JY AA J Resistor 3.9 1/16W Metal Oxide
R9635 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R9636 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R9637 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9638 VRS-CZ1JF303FY AA J Resistor 30k 1/16W Metal Oxide
R9639 VRS-CZ1JF562JY AA J Resistor 5.6k 1/16W Metal Oxide
R9640 VRS-CZ1JF562FY AA J Resistor 5.6k 1/16W Metal Oxide
R9641 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9643 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9645 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R9646 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R9648 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R9650 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9652 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9653 VRS-TW2HF1R0JY AA J Resistor 1 1/2W Metal Oxide
R9654 VRS-TW2HF1R0JY AA J Resistor 1 1/2W Metal Oxide
R9655 VRS-TW2HF1R0JY AA J Resistor 1 1/2W Metal Oxide
R9656 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9657 VRS-CZ1JF753FY AA J Resistor 75k 1/16W Metal Oxide
R9658 VRS-CZ1JF123FY AA J Resistor 12k 1/16W Metal Oxide
R9659 VRS-TW2HF1R0JY AA J Resistor 1 1/2W Metal Oxide
R9660 VRS-TW2HF1R0JY AA J Resistor 1 1/2W Metal Oxide
R9661 VRS-TW2HF3R3JY AA J Resistor 3.3 1/2W Metal Oxide
R9662 VRS-TW2HF3R3JY AA J Resistor 3.3 1/2W Metal Oxide
R9664 VRS-CZ1JF105JY AA J
Resistor 1M 1/16W Metal Oxide
R9665 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9666 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R9680 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R9681 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
RDA3301 PRDARA577WJFW AF J Heat Sink
SC501 QSOCNA770WJZZ AG J Socket
SC502 QSOCZA161WJZZ AG J Socket
SC503 QSOCZA161WJZZ AG J Socket
SC504 QSOCNA769WJZZ AG J Socket
SC1501 QSOCZA173WJQZY AG J Socket
SC1502 QSOCZA173WJQZY AG J Socket
SC1503 QSOCZA072WJZZQ AH J Socket
SC4401 QCNCMA332WJSA P Connector
TH3301 VHHM1103J03-1Y AC J Thermistor
!
TU1102 RTUDAA019WJQZ AZ J Tuner
VA3301 RH-VXA194WJZZY AC J Varistor AVRL161A1R1NTB
VA3302 RH-VXA194WJZZY AC J Varistor AVRL161A1R1NTB
X3301 RCRSCA207WJQZY P Crystal
X4401 RCRSCA039WJZZY AG J Crystal
N PSPAZB312WJKZ AD J Spacer
[4] CABINET AND MECHANICAL PARTS (LC-32LE600E/RU/S)
1 CCABAC371WJ12 N P Front Cabinet Ass'y
2 CCABBB619WJ12 N P Rear Cabinet Ass'y
2-2 HINDPD391WJSA N P Terminal Label
5 CANGKC375WJ02 N P Side Terminal Angle Ass'y
5-1 HINDPD470WJSA N P Side Terminal Label
8 LHLDWA289WJKZ AC N J Wire Holder, x2
17 QCNW-J895WJQZ N P Connecting Cord Main-Power(PD)
18 QCNW-J896WJQZ N P Connecting Cord Main-Power(LB)
21 QCNW-G182WJQZ AF J Connecting Cord Main-Power(PL)
24 QCNW-J712WJQZ P Connecting Cord Main-LCD Control(LP)
22 QCNW-K027WJQZ N P Connecting Cord Main-LCD Control(LW)
26 QCNW-J996WJQZ N P Connecting Cord(AS)
33 TLABZC352WJZZ N P POP Label (except for Russia)
33 TLABZC353WJZZ N P POP Label (for Russia)
35 XBPS730P06000 AA J Screw for HDMI, x3
N GCOVAD472WJ1A S P Bottom Cover
N QCNW-J892WJQZ N P Connecting Cord Main-R/C, LED-Key(RA/KM)
[5] LCD PANEL MODULE UNIT (LC-32LE600E/RU/S)
1-4 RUNTK4248TPZB N P LCD Control Unit
1-5 XHPS730P06WS0 AA J Screw, x4
1-22 R1LK315D3FZF0Y N P 32" LCD Panel Unit
1-28 LX-HZA039WJF7 AB J Screw, x8
N LX-HZA064WJF7 N P Wsher Screw, x2
[3] DUNTKF111FM11 (MAIN Unit)
