LC-32/40/46LE600E/RU/S (1st Edition)
15
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[6] CABINET AND MECHANICAL PARTS (LC-40LE600E/RU/S)
1 CCABAC372WJ12 N P Front Cabinet Ass'y
1-2 CDECQB299WJ12 N P Front Decoration Ass'y
2 CCABBB618WJ12 N P Rear Cabinet Ass'y
2-2 HINDPD391WJSA N P Terminal Label
5 CANGKC375WJ02 S P Side Terminal Angle Ass'y
5-1 HINDPD470WJSA N P Side Terminal Label
17 QCNW-J903WJQZ AK N J Connecting Cord Main-Power(PD)
18 QCNW-J904WJQZ N P Connecting Cord Main-Power(LB)
21 QCNW-J906WJQZ P Connecting Cord Main-Power(PL)
22 QCNW-K029WJQZ N P Connecting Cord Main-LCD Control(LW)
24 QCNW-J801WJQZ N P Connecting Cord Main-LCD Control(LP)
26 QCNW-J996WJQZ N P Connecting Cord(AS)
33 TLABZC322WJZZ N P POP Label (except for Russia)
33 TLABZC323WJZZ N P POP Label (for Russia)
35 XBPS730P06000 AA J Screw for HDMI, x3
N GCOVAD464WJ1A S P Bottom Cover
N LHLDQA001WJ1A S P Wire Holder
N PSLDMB651WJZZ S P Conductor: 10x60
N QCNW-J900WJQZ N P Connecting Cord Main-R/C, LED-Key(RA/KM)
[7] LCD PANEL MODULE UNIT (LC-40LE600E/RU/S)
1-3 RUNTK4248TPZA N P LCD Control Unit
1-4 XBPS730P06WS0 AA J Screw, x4
1-24 R1LK400D3FZC0Y N P 40" LCD Panel Unit
1-31 LX-BZA213WJF7 AA J Screw, x10
N LX-BZA348WJF7 N P Wsher Screw, x4
[8] CABINET AND MECHANICAL PARTS (LC-46LE600E/RU/S)
1 CCABAC378WJ12 N P Front Cabinet Ass'y
1-2 CDECQB309WJ12 N P Front Decoration Ass'y
2 CCABBB617WJ12 N P Rear Cabinet Ass'y
2-2 HINDPD391WJSA N P Terminal Label
5 CANGKC375WJ02 S P Side Terminal Angle Ass'y
5-1 HINDPD470WJSA N P Side Terminal Label
17 PSLDMB651WJZZ P Conductor: 10x60, x2
20 QCNW-H973WJQZ P Connecting Cord Main-Power(PL)
21 QCNW-J911WJQZ N P Connecting Cord Main-Power(PD)
22 QCNW-J912WJQZ N P Connecting Cord Main-Power(LB)
24 QCNW-K031WJQZ N P Connecting Cord Main-LCD Control(LW)
26 QCNW-J801WJQZ P Connecting Cord Main-LCD Control(LP)
28 QCNW-K104WJQZ N P Connecting Cord Power(AS)
34 TLABZC322WJZZ N P POP Label (except for Russia)
34 TLABZC323WJZZ N P POP Label (for Russia)
36 XBPS730P06000 AA J Screw for HDMI, x3
N GCOVAD479WJ1A P Bottom Cover
N QCNW-J908WJQZ N P Connecting Cord Main-R/C, LED-Key(RA/KM)
N LHLDQA001WJ1A S P Wire Holder
N RCORFA038WJZZ AH J Ferrite Core
[9] LCD PANEL MODULE UNIT (LC-46LE600E/RU/S)
1-3 RUNTK4248TPZZ N P LCD Control Unit
1-4 XHPS730P06WS0 AA J Screw, x4
1-5 QCNW-K183WJQZ N P Connecting Cord, x2
1-26 R1LK460D3FZN0Y N P 46" LCD Panel Unit
N LX-HZA064WJF7 N P Wsher Screw, x4
[10] SUPPLIED ACCESSORIES
X4 CDAI-A584WJ02 N P Stand Unit (LC-32LE600E/RU/S)
X4 CDAI-A586WJ02 N P Stand Unit (LC-40LE600E/RU/S)
X4 CDAI-A588WJ02 N P Stand Unit (LC-46LE600E/RU/S)
X5 TINS-E285WJZZ N P Operation Manual (for Europe except East Europe)
X5 TINS-E286WJZZ N P Operation Manual (for Sweden)
X5 TINS-E287WJZZ N P Operation Manual (for East Europe)
X5 TINS-E288WJZZ N P Operation Manual (for Russia)
[11] SERVICE JIGS (USE FOR SERVICING)
N QCNW-K037WJQZ J Main+LCD Control-Power(LB)
N QCNW-K039WJQZ J Main-R/C, LED-Key(RA/KM)
N QCNW-G616WJQZ J Connecting Cord Main-LCD Control(LW)
N QCNW-H347WJQZ J Connecting Cord Main-LCD Control(LP)
N QCNW-G625WJQZ J Connecting Cord Main-Power(PL)
N QCNW-H184WJQZ J Connecting Cord Main-Power(PD)
N QCNW-J413WJPZ J Connecting Cord Main-Speaker(SP)
