Sharp LC-40LE530E

119
LC-32LE530
LC-40LE530
CABINET AND MECHANICAL PARTS LISTING
20565061 FRONT 32942 LED(STEAM-PC-ABS/I(V0_SH)( Front Cabinet LC-32LE530
)
G--
20565095 BC.32942 LED MB61&RO WO/KL&CH(I)V0(SHA) (Back Cover LC-32LE530
)
G--
40046849 LENS COSMETIC 32942 LED SILV.BRUS HST (On front Cabinet) LC-32LE53
0
G--
35028064 METAL_PLATE_MB61_LED32_2011 (Metal plate, under Main Board LC-32LE530 ) G --
35028347 METAL FOOT SUPPORT LED_LCD32_SHARP_2011( Metal Plate for stand foot support ( LC-32LE530
)
G--
CABINET AND MECHANICAL
PARTS LISTING
REF No. PARTS DESCRIPTION *
PRICE
CODE
20569417 ROC.SW.AS. (MB60_22942_SHARP) ( Rocker Switch & Cable LC-32LE530
)
G--
20562171 FOOT ASSY 32942(GLOSSY-BLACK_SHARP(PKG) ( Stand Foot Detachable LC-32LE530) G --
45010585
DETACHABLE SHARP ST.BLACK LCD32 LED PKG (Screws and Foot Support of the Detachable Stand Foot L-C32LE530
)
G--
20565238 SPK.AS.32930 LED(MB61_6P(30X107X20(BL(SH) ( Speakers LC-32LE530
)
G--
30071176 CNAS 28P/450 SIS W/DC MB61UL1007 #24SHARP (DC Voltaje cable, between power board and main board )LC32LE53
0
G--
30070913 CNAS 12P+14P/190SIS W/DC UL1007AWG24SHARP (Panel Inverter Cable, between Power Board and panel LC-32LE530) G --
20578397 CN.A.FFC 51P/400P=05mmLVDS( 32" 100Hz_MB61( LVDS FFC Cable, between panel and Main Board LC-32LE530) G --
20578738 CNAS FFC 41P/400 LVDS FI-R SHL (32" MB61)( LVDS FFC Cable, between panel and Main Board LC-32LE530) G --
20566988 FRONT 40942 LED (BS&SHARP/S) (Front Cabinet LC-40LE530
)
G--
20567117 BC.40942 L 61 &S&R&L(WO/KL&C&CH(I)V0(SHA) (Back Cover LC-40LE530
)
G--
40046850 LENS COSMETIC 40942 LED SILV.BRUS HST. COSMETIC LENS (On front Cabinet) LC-40LE53
0
G--
35028221 METAL FOOT SUPPORT LED_LCD40930 (Metal plate for stand foot support LC-40LE530
)
G--
35028237 METAL_PLATE_MB61_LED40_42_46_2011 ( Metal plate, under mainboard LC-40LE530 ) G --
20573118 ROC.SW.AS.40"LED(MB61_SHARP) (Rocker Swith Cable LC-40LE530 ) G--
20565284 FOOT ASSY 40942(GLOSSY-BLACK_SHARP(PKG ) (Stand Foot detachable LC-40LE530 ) G --
45010587 DETACHABLE SHARP ST. BLACK LCD40 LED PKG ( Screws and Foot Support of the detachable stand foot LC-40LE530
)
G--
35028234 METAL_PLATE_PW07_LED40 (Metal Plate, unde System Power LC-40LE530 ) G--
20567455 SPK.AS.42930 LED(MB61_6P(R/L(30X131)(BL-SHARP) (Speakers LC-40LE530) G--
30071217 CNAS 28P/300 SIS W/DC MB61UL1007#24SHARP (DC voltage cable, between power board and Main Board LC40LE530
)
G--
30071199 CNAS 12-14P/500 SISW/DCINV FLT2468#24SHA( Panel Inverter cable, between
p
ower board and
p
anel LC-40LE530 ) G --
3799
N S /5 S SW/D NV FL 68 SH ( anel nverter cable, between power board and panel L LE53 )
G
30068404 CNAS 50P/420 LVDS W/4C+SHL UL1571#30 ROH(LVDS FFC Cable, between panel and mainboard LC-40LE530 ) G --
40046689 BRACKET IO MB61S 2011 VER5(I)ABS(V0(SHA) ( Side Bracket i/O
)
G--
40044553 COVER GROMET 30x30 (I(VO)) GROMET COVER ON BACK COVER G--
40043424 LED IR LENS TFT XX856 (%3 MILKY ) VERG. ( I/R LENS
)
G--
30069634 CNAS 8P-6/700 CY W/DC UL1571AWG28 RoHS ( Touch pad cable
)
G--
20562101 R/C 1910 SHARP&1910 (GRAY/S) ( Remote Controller
)
G--
20561436 SHARP LC-32LE530E ( Owner Manual & Accesories (Batteries, YPBPr Cable, Stereo to RCA cable, R/C
)
G--
20563308
SHARP LC 40LE530E ( O n r M nu l & Acc s ri s ( B tt ri s YPBPr C bl St r t RCA c bl R/C)
G
ACCESSORIES PARTS LISTING
20563308 SHAR
P
LC-40L
E
530
E
(
Owner Manua
l
&
Accesories
(
B
atteries, Y
PBP
r Ca
bl
e, Stereo to RCA ca
bl
e, R
/
C
)
G
--
! 30070136 PWR CORD SAFE EU 1800-70 W/GR+H 3P ROHS ( Power cord EU plug LC-32LE530 ) G --
! 30067655 PWR CORD SAFE EU 1800-440MM W/GR 3P ROHS ( Power cord EU plug LC-40LE530 ) G --
50185772 CARTON BOX SHARP LC-32LE530E G--
20556710 SNOW BOX ASSY (T/B) 32930 LED (Top, Bottom Pack-ad LC-32LE530) G--
20548318 SNOW BOX MIDDLE 200X130X170 (middle Pack-ad LC-32LE530) G--
50186871 CARTON BOX SHARP LC-40LE530E G--
PACKING PARTS LISTING
50186871
CARTON
BOX
SHARP
LC 40LE530E
G
20556808 SNOW BOX ASSY (T/b) 40930_LED ( Top, Bottom Pack ad LC-40LE530) G--
20508607 SNOW BOX MIDDLE 200x195x210 (I) ( Middle Pack-ad LC-40LE530) G--
