41
LC-32LE530
LC-40LE530
Headphone Amplifier-TDA1308
The TDA1308 is an integrated class AB stereo headphone driver.
x Power supply maximum 60 mW to 327+'
x 5V single supply
x SNR 110 dB
x Power supply ripple rejection
